Hardness Rubber Testing Machine / Desktop Shore Hardness Meter
Product description
Rubber hardness tester is the reaction to combination property of the rubber , and the shore durometer is one of the precise tester to test the hardness of the rubber . This produce adopt to international organization for standard production and test by <ISO 868-1986 plastics and ebonite . determination of indentation hardness by means of a durometer shore hardness> and < Rubber , vulcanized or thermoplastic — Determination of indentation hardness> . It can be divided into desk top hardness tester and portable hardness tester accordingly to operating requirement .
Main technical parameters
| Model Number | HD-G803 |
| Certification | CE/ROHS/UL |
| Delivery | in stock and prompt ship |
| Hardness reading | Digital display |
| Accuracy | ±1HA |
| Pressure needle stroke | 0-2 . 5mm |
| Sell point | high quality , best price |
Type of construction
Rubber hardness tester mainly divide into Shore A , Shore D , Shore O accordingly to press needles sharp .
And the hardness tester’s model , please refer to the below table :
| type | Total dynamometry | External press | Measuring head sharp | Needle length | Dial plate |
| A | 8 . 1N | 1Kg | 35° | 2 . 5 | 0-100 |
| D | 44 . 5N | 5Kg | 30° | 2 . 5 | 0-100 |
| O | 8 . 1N | 1Kg | R=2 . 38 | 2 . 5 | 0-100 |
NOTED :
Rubber hardness tester should use shore A or shore D by the normal test , we suggest you choose the shore D or other type when the hardness value more than 90 . Please keeping properly after using .
NOTED:
it should use shore A or shore D by the normal test, we suggest you choose the shore D or other type when the hardness value more than 90. Please keeping properly after using.
